Accessories For Evaluation/Development Boards

Image	Description	Ordering Information
AirMax/Interlaken Modules
	The HTG-CFP extender/carrier card is designed for hosting 100Gig CPF Multi-Source Agreement (MSA) hot-pluggable optical transceiver form factor to enable 40Gb/s and 100Gb/s applications. This carrier card mates with HiTech Global Virtex-6 HXT 40G/100G, Stratix IV 40G/100G, or any Interlaken compatible platforms. It can also be used in stand-alone mode. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-S4G-100GIG (Altera Stratix IV GT/GX) More info..	Part Number: HTG-CFP-MDL
	The HTG-SFP+ extender/carrier card is designed for hosting 12 SFP+ optical transceiver ports. This carrier card mates with HiTech Global Virtex-6 HXT 40G/100G, Stratix IV 40G/100G, or any Interlaken compatible platforms. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-S4G-100GIG (Altera Stratix IV) More info..	Part Number: HTG-SFP-PLUS-MDL
	The HTG-SMA extender module provides access to 12 serial transceivers through 48 SMA connectors (12Tx/12Rx). This module mates with HiTech Global Virtex-6 HXT 40G/100G, Stratix IV 40G/100G, or any Interlaken compatible platforms. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-S4G-100GIG (Altera Stratix IV) More info..	Part Number: HTG-AIRMAX-SMA
	The SMA loopback module provides loopback function for Rx/Tx serial transceivers. This module mates with HiTech Global Virtex-6 HXT 40G/100G, Stratix IV 40G/100G, or any Interlaken compatible platforms. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-S4G-100GIG (Altera Stratix IV)	Part Number: HTG-AMAX-LOOPBACK
	The CFP2SFP+ conversion module is pluggable into optical systems with 40G/100G CFP (MSA) interface. This module receives four serial transceivers (SerDes) signals from a CFP port and brings them to four SFP+ ports each running at 10Gbps. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-S4G-100GIG (Altera Stratix IV)	Part Number: HTG-CFP2SFP+
FMC Modules
	FMC daughter card with one QSFP+ and two SFP+ connectors with default clocks for CPRI/OBSAI (other clocks can also be supported) Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info	Part Number: HTG-FMC-SFP-OC Price:$795 [Buy Online]
	The dual SFP+ is a FPGA Mezzanine Connector (FMC) daughter card with two SFP+ connectors and two 10Gbps physical layer transceivers which provides full PCS, PMA and XGXS sub-layer functionality. The onboard 156.25MHz and 125MHZ clocks provide required clocks for the 1Gbps and 10Gbps operations. Interace to the FPGA (through the FMC connector) is implemented by XAUI (4 x 3.125Gbps) Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info	Part Number: HTG-FMC-SFP-PLUS Price: $965.00 [Buy Online]
	The dual CX4 is a FPGA Mezzanine Connector (FMC) daughter card with two CX4 connectors and clock circuitry providing access to two 10Gbps interfaces implemented by two XAUI (4 x 3.125Gbps) channels. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info..	Part Number: HTG-FMC-2CX4 Price: $595 [Buy online]
	FMC daughter card with one CX4, two SATA, and two SMA ports (interfacing to total of 8 serial transceivers). Each port has its own on-board dedicated clock for maximum flexibility and ease of use. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info..	Part Number: HTG-FMC-CX4-SATA-SMA Price: $545.00 [Buy online]
	The FMC x8 PCI Express Gen 1/ Gen2 is a FPGA Mezzanine Connector (FMC) daughter card with support for 8 lanes of PCI Express Root Complex (interfacing to total of 8 serial transceivers). Reference clock for the serial transceivers of the carrier board is provided by the module's super clock . Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info..	Part Number: HTG-FMC-PCIE-RC Price: $695 [Buy online]
	The FMC SFP/SATA Module is a double-size FPGA Mezzanine Connector (FMC) daughter card with four SFP and four SATA ports (interfacing to total of 8 serial transceivers). The SFP and SATA ports have their own on-board dedicated clock for maximum flexibility and ease of use. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More Info..	Part Number: HTG-FMC-4SFP-4SATA Price: $695 [Buy online]
	The FMC SMA-LVDS Module is a single-size FPGA Mezzanine Connector (FMC) daughter card with eight SMA ports (interfacing to total of 8 serial transceivers) and 66 pin headers interfacing to 66 single-ended or 33 LVDS I/Os. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info..	Part Number: HTG-FMC-SMA-LVDS Price: $595
	The FMC x8 SMA port is a double-size FPGA Mezzanine Connector (FMC) daughter card with support for 8 SMA ports through 32 SMA connectors. Reference clock for the serial transceivers of the carrier board is provided by the module's super clock as well as a pair of SMA connectors for external pulse generators. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More Info..	Part Number: HTG-FMC-8SMA Price: $695 [Buy online]
	The FMC AD/DA Module is a double-size Mezzanine Connector (FMC) daughter card with two 16-bit AD and DA channels. Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5) More info..	Part Number: HTG-FMC-DA-AD Price: $1,795 [Buy online]
Modules
	- PCI Express Test - Provides incoming clocks ranging from 100MHz to 250MHz and power (12V and 3.3V) for quick electrical verification of any PCI Express card (Gen1, 2, or 3). - PCI Express Loopback Test - PHY or Serial Transceivers used as PHY can be tested for functionality and performance - Serial Transceiver Expansion - Serial Transceivers used as PCIe PHY can be used for other serial interfaces through SMA cables Supported Boards: HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-PCIE-200/240/300 (Xilinx Virtex-5 FX200T/SX240T/LX330T) HTG-V5-PCIE-95/100/110 (Xilinx Virtex-5 SX95T/FX100T/LX110T) More info...	Part Number: HTG-TEST-PCIE-SMA Price: $695 [Buy Online]
	SMA to SFP/SFP+ Conversion Module Supported Boards: HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-PCIE-200/240/300 (Xilinx Virtex-5 FX200T/SX240T/LX330T) HTG-V5-PCIE-95/100/110 (Xilinx Virtex-5 SX95T/FX100T/LX110T) More info..	Part Number: HTG-SFP-SMA Price: $495 [Buy online]
	10-port SFP module Supported Boards: HTG-V5-PCIE-200/240/300 (Xilinx Virtex-5 FX200T/SX240T/LX330T)	Part Number: HTG-X10-SFP Price: $695
Systems
	4-port x16 PCI Express Gen2 PC (with Rackmount 4U Chassis option) Supported Boards: HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-PCIE-200/240/300 (Xilinx Virtex-5 FX200T/SX240T/LX330T) HTG-V5-PCIE-95/100/110 (Xilinx Virtex-5 SX95T/FX100T/LX110T) HTG-V5TXT-PCIE (Xilinx Virtex-5 TXT)- NetFPGA10G	Part Number: HTG-PC-X4X16 (standard PC chassis) Part Number: HTG-PC-X4X16-4U (Rack mount 4U Chassis 650W)
Cables
	HP ProCurve 1m Direct Attach Cable (J9281B) with 10Gbps SFP+ connection Supported Boards: HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-FMC-SFP-PLUS (Dual SFP+ Module) HTG-V6-PCIE (Xilinx Virtex-6) HTG-V5TXT-PCIE (Xilinx Virtex-5 TXT)- NetFPGA10G	Part Number: HP-J9281B Price: $195 [Buy online]
	FMC To FMC cable (5" and 9") Carrier Boards: HTG-V6HXT-100GIG (Xilinx Virtex-6 HXT) HTG-V6HXT-X16PCIE (Xilinx Virtex-6 HXT) HTG-V6HXT-X8-PCIE (Xilinx Virtex-6 HXT) HTG-V6-PCIE (Xilinx Virtex-6) HTG-S4GX-PCIE (Altera Stratix IV GX/GT) HTG-V5-100GIG (Xilinx Virtex-5)	Part Number:FMC-TO-FMC-9 (9" length) Price: $820 [Buy online] Part Number:FMC-TO-FMC-5 (5" length) Price: $540 [Buy online]
	FMC connector used on daughter cards	Part Number: ASP-124488-01 [Buy online]
	FMC connector used on FPGA carrier boards	Part Number: ASP-124486-01 [Buy online]
	SMA to SMA Cable Impedance: 50Ω Propagation Delay: 4.83 nsec/meter Max Attenuation: 1.25dB @ 1GHz for 1 meter Conductor Material: Silver Plated Copper Conductor Resistance: 0.13Ω/meter max Current Rating: 5A DC Dielectric Constant: 2.1dK	Part Number: SMA-2-SMA-24 Price: $14.95 (24" length) [Buy online] Part Number: SMA-2-SMA-12 Price: $12.95 (12" length) [Buy online]
	Xilinx Programming Cable (Jtag/USB) Supported Boards: All Xilinx FPGA based boards	Part Number: HW-USB-II-G Price: $225 [Buy online]
	High speed cable for connecting IO signals through Samtec QSE connectors Supported Boards: HTG-V6-PCIE (Xilinx Virtex-6) HTG-V5-PCIE-200/240/300 (Xilinx Virtex-5 FX200T/SX240T/LX330T) HTG-V5-PCIE-95/100/110 (Xilinx Virtex-5 SX95T/FX100T/LX110T)	Part Number: QSE-TO-QSE Price: $175 [Buy online]
