QorIO P2010/P2020 Communication  Platform








l

Powered by Freescale QorIO P2010 or P2020 communication processor and supported by FPGA Mezzanine Connector, the HTG-P20 is an excellent platform for rapid and flexible development of high-end communication applications. This platform can be used in x4 PCI Express, Stand Alone, or FPGA Interface mode.

The HGT-P20 platform can communicate with the following Xilinx Virtex or Altera Stratix boards through its on-board FPGA Mezzanine Connector (FMC):

HTG-V6-PCIE
HTG-S4-PCIE
HTG-V5-100GIG






Features:

► Freescale QorIQ Communication Processor P2010 or P2020
► x4 PCI Express End-point
► x4 Serial RapidIO for FPGA interface
► FPGA Mezzanine Connector (FMC)
► USB 2.0 Host
► USB 2.0 Device
► x3 Gigabit Ethernet Ports ( 2 with SGMII support)
► Up to 4GB DDR III SODIMM
► SD Card Port
► SPI Flash
► Mictor Connectors
► GPIO Headers
► PCI Express, Stand-alone, or FPGA operational modes
► Size : 6.6" x 4.25"


 Ordering information

Part Number: HTG-FMC-P20
Price:

Availability: Feb 2010
