►Features:

• Virtex-4 FPGA in FF1513 package (XC4VLX100, LX160 or LX200 devices)
• Typical core speeds 50 to 120MHz (depending on speed grade and core configurations)
• In circuit programmability with JTAG interface or Slave Serial/Parallel interface
• On board configuration proms (64Mbit: 2 x XCF32P as standard configuration)
• Standard Compact PCI plug-in format (3U 4HP, 32/64 bit, 33/66MHz, 3.3V)
• Configurable as PCI plug-in card in either SYSTEM or PERIPHERAL slots
• Capable of being used in standard PC PCI slots using adapter board
• SDRAM:  SO-DIMM socket (up to 64M x 64 bit)
• FLASH: 128Mbit on-board (4M x 32 bit)
• SRAM:  via Memory Expansion connector and Mezzanine board
• Serial/Debug Support Unit interface (RS232, standard SUB-D9 female connector)
• Memory expansion connector (120 pin expansion connector: AMP 177-984-5)
• User I/O Connectors (up to 172 user defined i/o connections with 120 pin and 60 pin connectors: AMP 177-984-5 and -2)
• Ethernet PHY 10/100 transceiver, with RJ45 10/100Mbit Ethernet connector
• GPIO expansion connector (16 user defined i/o connections on 20 pin 0.1” header)
• GPIO interface expandable with optional 2 x RS232 / 2 x RS422 / 2 x LVDS / 2 x CAN interfaces
• Front panel connector for boundary scan (JTAG) Test Access Port
• 5V power input, either from external power supply (in stand-alone operation) or from
+5V PCI power supply via PCI connector pins. (configurable also to operate from 3.3V)
• On-board voltage regulators generating +3.3V and +2.5V/+1.8V/+1.2V regulated power supply voltages for the memory/peripherals and FPGA core respectively
• Standard Compact PCI plug-in format (3U 4HP, 32/64 bit, 33/66MHz, 3.3V)
• Configurable as PCI plug-in card in either SYSTEM or PERIPHERAL slots
• Capable of being used in standard PC PCI slots using adapter board
