FPGA Boards Selection Guide

Coming Soon:

Xilinx RFSoC Half Size PCIE Platform











Coming soon:

Xilinx Versal Prime and AI platforms

HTG-930
Xilinx
Virtex™ UltraScale+ PCI Express Gen4

PCI Express x8 Gen4 /x16 Gen3 platform with three Vita57.4 FMC+ ports (370 single-ended FPGA I/Os, and  56 GTY (30.5G) serial transceivers) , DDR4 SODIMM (up to 16GB) , GPPO ports, USB/UART port, and Power Management BUS.
More info..
Supported FPGA Devices:
XCVU9P-2FLGB2104E
XCVU13P-2 FHGB2104E

XCVU190-2FLGB2104E

HTG-840
Xilinx Virtex UltraScale PCIE/SOC Platform

8-lane Gen3 PCI Express / SOC development platform with one Virtex UltraScale 440 FPGA, two DDR4 SODIMM sockets (up to 32GB), four Vita57.1 FMC HPC connectors (total of  640 single-ended I/Os and 12 GTH transceivers), one high-speed Z-Ray GTH gigabit port (16x16G), BPI configuration Flash, USB/UART port, and XADC headers
More info..
Supported FPGA Device:
XCVU440-2FLGB2377E


HTG-937
Xilinx
Virtex™ UltraScale+ HBM Platform

PCI Express x8 Gen4 /x16 Gen3 platform with three Vita57.4 FMC+ ports, one DDR4 SODIMM (up to 16GB) ,  USB/UART port and Power Management BUS.
More info..
Supported FPGA Device:
XCVU37P-2FSVH2892E4539
XCVU47P-2FSVH2892E4539

HTG-Z922
Xilinx Zynq® UltraScale+™ MPSoC
PCI Express Development Platform

8-lane Gen4/ 16-lane Gen3 PCI Express platform with three FMC+/FMC  expansion connectors, two 16GB SODIMM Sockets (PS and PL sides), USB/UART port,
More info..
Supported FPGA Devices:
XCZU11EG-3FFVC1760E
XCZU19EG-2FFVC1760E

HTG-Z920
Xilinx Zynq® UltraScale+™ MPSoC
PCI Express Development Platform

8-lane Gen4/ 16-lane Gen3 PCI Express platform with two FMC  expansion connectors, one high-speed Z-Ray  gigabit port , USB/UART port, DDR4 SODIMM & components
More info..
Supported FPGA Devices:
XCZU11EG-3FFVC1760E
XCZU19EG-2FFVC1760E

HTG-ZRF8
Xilinx Zynq® UltraScale+™ RFSoC
PCI Express Development Platform

8-lane Gen4  PCI Express platform with eight ADC/DAC ports, one FMC+  expansion connector, USB/UART port, Ethernet, Display Port, MicroSD, SATA, USB3, DDR4 SODIMM & components
More info..
Supported FPGA Devices:
XCZU28DR-2FFVG1517
XCZU48DR-2FFVG1517

HTG-940
Xilinx
Virtex™ UltraScale+ Platform

Four Vita57.4 FMC+ ports,  (364 single-ended FPGA I/Os, and  72 GTY (30.5G) serial transceivers) , one 100Gbps QSFP28 port, one DDR4 SODIMM (up to 16GB) , one 10/100/1000 Ethernet port,  USB/UART port, and Power Management BUS.

More info..
Supported FPGA Devices:
XCVU9P-2FLGB2104E
XCVU13P-2 FHGB2104E

XCVU190-2FLGB2104E

HTG-ZRF16
Xilinx
ZYNQ™ UltraScale+ 16ADC/16DAC Platform

16ADC (12-bit @2GSPS)/16DAC (16-bit@6.4GSPS
or 14-bit @10.0 GSPS) ports , two QSFP28 (100G) optical ports, one DDR4 SODIMM (16GB) for PL / 2-4 GB Components for the PS , 10/100/1000 Ethernet, SATA, Display port, USB3.0 and FMC+ port ( with 116 single-ended I/Os  and 8 GTY (32.75Gbps) Serial Transceivers )
More info..
Supported FPGA Devices:
XCZU29DR-2FFVF1760E
XCZU
49DR-2FFVF1760E

 HTG-ZRF-HH
Xilinx
ZYNQ™ UltraScale+

Low-Profile x8 Gen4/3 PCI Express platform with expansion port providing access to 8 ADC/DAC channels, 16GB DDR4 (8GB for the PS & 8GB for the PL), one I/O expansion port with GTY and LVDS I/Os, USB3, Ethernet, SATA, Display port. Supported by different add on cards providing access to different configurations of ADC, DAC and optical interfaces.

More info..
Supported FPGA Devices:
XCZU28DR-2FFVG1517
XCZU48DR-2FFVG1517

HTG-910
Xilinx
Virtex™ UltraScale+ Low-Profile PCI Express

Low-Profile x8 Gen4 PCI Express with two QSFP28 (100G), 34GB of DDR4 memory (3 independent banks) , two 100G FireFly ports, Z-RAY high speed serial port (x16 GTY)

More info..
Supported FPGA Devices:
XCVU9P-2FLGB2104E
XCVU13P-2 FHGB2104E

XCVU190-2FLGB2104E

HTG-K800
Xilinx
Kintex™ UltraScale Half-Length x8 PCI Express Platform

8-lane Gen3 PCI Express platform with two Vita57.1 FMC HPC expansion ports (total  of 20 GTH transceivers and 320 single-ended I/Os) , five  DDR4 components (2.5GB),  one high-speed Z-Ray GTH gigabit expansion port (16x16G), 1Gb embedded flash,  XADC headers, and USB/UART port

More info..
Supported FPGA Devices:
XCKU060-2FFVA1517E , XCKU060-3FFVA1517E,
XCKU085-2FLVA1517E, XCKU085-3FLVA1517E,
XCKU115-2FLVA1517E,  XCKU115-3FLVA1517E

HTG-830
Xilinx Virtex / Kintex UltraScale Development Platform

8-lane Gen3 PCI Express platform with two Vita57.4 FMC+ connectors (total of 320 single-ended I/Os, 20 GTY, and 22 GTH transceivers), one vita57.1 FMC connector (24 single-ended I/Os and 10 GTH transceivers), high-speed     Z-Ray GTY gigabit port (16x30G), one DDR4 SODIMM socket (up to 16GB), Embedded flash (1Gb) for configuration, XADC headers, and USB/UART port
More info..

Supported FPGA Devices:
XCVU190-2FLGB2104E
XCVU095-2FFVB2104E
 XCKU115-2FLVB2104E

HTG-K810
Xilinx
Kintex™ UltraScale COM Express Platform

Type 6 COM Express with one Vita57.1 FMC HPC expansion ports (24 GTH transceivers and 160 single-ended I/Os) , five  DDR4 components (2.5GB),   1Gb embedded flash,   and USB/UART port

More info..
Supported FPGA Devices:
XCKU060-2FFVA1517E or Industrial
XCKU085-2FLVA1517E
XCKU085-3FLVA1517E
XCKU115-2FLVA1517E

HTG-K805
Xilinx
Kintex™ UltraScale Half-Length x16 PCI Express Platform

16-lane Gen3 PCI Express platform with four QSFP+ ports, one Vita57.4 FMC+ HPC expansion port ( 16 GTH transceivers and 160 single-ended I/Os) , five  DDR4 components (2.5GB), 1Gb embedded flash,  XADC headers, and USB/UART port

More info..
Supported FPGA Devices:
XCKU085-2FLVA1517E, XCKU085-3FLVA1517E,
XCKU115-2FLVA1517E,  XCKU115-3FLVA1517E

HTG-Z999
Xilinx
Zynq™ UltraScale+  Platform

FMC daughter card or stand alone board with two FMC (Vita57.1) ports, ZRAY  interposer, DDR4 memory, ARM Debug port, Flash, and UART/USB port
More info..
Supported FPGA Devices:
XCZU6EG-2FFVB1156E ,  XCZU9EG-2FFVB1156E ,
XCZU15EG-2FFVB1156E

 HTG-STX10
Intel/Altera Stratix 10 PCI Express Platform

PCI Express x16 Gen3 platform with three Vita57.4 FMC+ ports (240 LVDS FPGA I/Os, and  64 GXT serial transceivers) , DDR4 SODIMM (up to 16GB) , USB/UART port and Power Management BUS
More info..

Supported FPGA Devices:
1SG280HU2F50E2VG
1SG
210HU2F50E2VG

HTG-A100
Altera
Arria10™ Half-Length PCI Express Development Platform

x8 Gen3 PCI Express platform with two FMC HPC ports (total  of 20 serial transceivers and 320 single-ended I/Os) , DDR4 (2.5GB), high-speed Z-Ray  gigabit port , USB/UART port, and USB/UART port
More info..
Supported FPGA Devices:
10AX057N2F40E2SG
 10AX115N2F40E2SG

HTG-K816
Xilinx Kintex UltraScale Half-Size PCI Express Platform

Half-size (6.6"x2.5") Gen3 PCI Express platform with one front pannel high-speed Z-Ray GTH gigabit port (16x16G), ten DDR4 components (5GB), two board-to-board connectors (LVDS & serial) , GPS port, mini UART/USB port and supported by series of Z-RAY modules including QSFP+, SFP+, and  Hybrid Memory Cube (HMC)
More info..
Supported FPGA Devices:
XCKU035-2FFVA1156E , XCKU040-2FFVA1156E
XCKU060-2FFVA1156E

HTG-9200
Xilinx
Virtex UltraScale+ Optical Networking Platform

Optical Networking platform with nine QSFP28 ports(9x100G or 9x40G), one Vita57.4 compliant FMC+ connector (160 single-ended I/Os and 24 GTY transceivers),  four SMA ports (4x16G), two banks of DDR4 memory components (5GB) , one Samtec FireFly port (12x16G), and USB/UART port

More info..

Supported FPGA Devices:
XCVU9P-2FLGB2104E
XCVU13P-2 FHGB2104E

XCVU190-2FLGB2104E

HTG-9100
Xilinx
Virtex UltraScale 900G Optical Networking Platform

Optical Networking platform with four CFP4 ports(4x100G), five QSFP28 ports (5x100G), one Vita57.4 compliant FMC+ connector (160 single-ended I/Os and 24 GTH transceivers),  four SMA ports (4x16G), two banks of DDR4 memory components (5GB) , one Samtec FireFly port (12x16G), and USB/UART port

More info..

Supported FPGA Devices:
XCVU190-2FLGB2104E
XCVU160-2FLGB2104E
XCVU095-2FLGB2104E

HTG-847
Xilinx Virtex UltraScale ASIC/SOC Emulation Platform

ASIC/SOC Emulation /development platform with four (or two) Virtex UltraScale 440 FPGAs (-2 or -3 speed grade) , four 72-bit ECC DDR4 SODIMM sockets (total of 64GB) , total of eight Vita57.1 compliant FMC connectors for I/O expansion (total of 1280 single-ended I/Os and 80 GTH serial transceivers), total of four Vita57.4 compliant  FMC+ connectors (total of 640 single-ended I/Os and 64 GTH serial transceivers), one Kintex 7 FPGA for configuration, housekeeping and management, two jtag ports, BPI and SPI flash devices, UART, 1G Ethernet with PHY, USB, and supported by wide range of FMC/FMC+ daughter cards for quick functional expansions. Supported by complimentary reference designs (chip-to-chip differential & serial, DDR4, and IBERT)
More info..

Supported FPGA Device:
XCVU440-2FLGA2892E

HTG-710
Xilinx Virtex 7 PCI Express / Dual CXP Networking Platform

8-lane Gen2/3 PCI Express platform with two CXP ports (12x10G each) , one FMC HPC expansion connector (160 single-ended I/Os and 4 GTX/GTH) transceivers, two QDR II components (144Mb) ,  two DDR3 SODIMM sockets (up to 16GB), and USB/UART port

More info..
Supported FPGA Devices:
XC7V2000T-2FHG1761C, XC7VX690T-2FFG1761C,
XC7VX690T-3FFG1761E, XC7V585T-2FFG1761C

HTG-K700
 Xilinx Kintex 7 half-length PCI Express Platform

8-lane Gen2/3 PCI Express platform with one front panel FMC HPC expansion connector (160 single-ended I/Os and 8 GTX transceivers) , one DDR3 SODIMM socket (up to 8GB), 1Gb embedded BPI flash for configuration , and USB/UART port

More Info..
Supported FPGA Devices:
XC7K410T-2FFG900, XC7K410T-3FFG900
XC7K325T-2FFG900, XC7K325T-3FFG900

HTG-700
Xilinx Virtex 7 PCI Express / SOC Development Platform

8-lane Gen2/3 PCI Express development platform with three FMC HPC expansion connectors (total of 480 single-ended I/Os and 24 GTX/GTH transceivers) , four SMA ports, one DDR3 SODIMM socket  (up to 8GB), USB/UART port, and BPI configuration flash
More info..
Supported FPGA Devices:
XC7V2000T-2FHG1761C, XC7VX690T-2FFG1761C,
XC7VX690T-3FFG1761E, XC7V585T-2FFG1761C

HTG-828
Xilinx
Virtex™ UltraScale 100G NIC

100GIG Networking platform with x16 Gen3 PCI Express, two CFP4 ports, one QSFP28 port,  one QDR IV (144Mb)  , two DDR4 banks (5GB), Mini SMP ports , one  Z-Ray GTY port (16x30G), one  FMC+ (Vita57.4) port with 24 GTH (16G) and 160 single-ended I/Os, and USB/UART port
More info..
Supported FPGA Devices:
XCVU190-2FLGB2104E , XCVU095-2FLGB2104E

HTG-777
Xilinx Virtex 7 Stackable Development Platform

Small form factor FMC pluggable / Stackable development platform with three FMC HPC connectors (total of 480 single-ended I/Os and 24 GTH/GTX transceivers), one DDR3 SODIMM socket (up to 8GB), BPI flash, and USB/UART port
More info.
Supported FPGA Devices:
XC7V2000T-2FHG1761C, XC7VX690T-2FFG1761C,
XC7VX690T-3FFG1761E, XC7V585T-2FFG1761C

HTG-703
Xilinx
Virtex 7 PCI Express Gen 3 /100Gig Networking  Platform

8-lane Gen2/3 PCI Express development platform with  one FMC HPC expansion connector (160 single-ended I/Os and 10 GTH transceivers), two SMA GTH ports, one DDR3 SODIMM socket (up to 8GB),   QDR II, four SFP+ (4x10G), one QSFP+ (1x40G), and two Avago MiniPod optical ports (24 GTH)

More info...

Supported FPGA Devices:
XC7VX690T-2FFG1927C, XC7VX690T-3FFG1927E,
XC7VX415T-2FFG1927C, XC7VX415T-3FFG1927E

HTG-747
Xilinx Virtex 7 ASIC/SOC Emulation  Platform


ASIC/SOC development platform with four Virtex-7 V2000T FPGAs, four DDR3 SODIMM sockets (total of 32GB) ,  eight FMC connectors for I/O expansion (total of 1280 single-ended I/Os and 32 GTX serial transceivers)
, UART, four pairs high-speed board to board AirMax connectors for daisy chain expansion, 1G Ethernet, USB, and one Kintex-7 FPGA for general configuration and management
More info..

Supported FPGA Devices:
XC7V2000T-2FLG1925

HTG-728
Xilinx
Virtex 7 100Gig Network Interface Card  (NIC)

16-Lane Gen3 PCI Express platform with one CFP2 (4x25G), one CFP4 (4x25G),  Cypress QDR IV (144Mb), two DDR3 SODIMM sockets (16GB) ,  two Avago Minipod ports (24 GTH transceivers), one FMC HPC connector (64 single-ended I/Os and 8 GTH transceivers), and USB/UART port

More Info..


Supported FPGA Device:
XC7VH580T-HCG1931

HTG-Z100
Xilinx Zynq Networking Platform

8-Lane Gen 2 PCI Express platform with one QDR-IV memory (144Mb),  ten DDR3 components  two QSFP+ (2x40G) ports, embedded configuration Flash , MicroSD, expansion headers, GPS,  IP Protection Circuit , and  USB/UART port
More Info..

Supported FPGA Device:
XC7Z100-2FFG1156I

HTG-712
Xilinx Virtex 7 PCI Express / FireFly Networking Platform

8-lane Gen2/3 PCI Express platform with one Samtec FireFly port (12x10G) , one FMC HPC expansion connector (160 single-ended I/Os and 10 GTX/GTH transceivers), two QDR II components (144Mb) ,  two DDR3 SODIMM sockets (up to 16GB), and USB/UART port
More info..
Supported FPGA Devices:
XC7V2000T-2FHG1761C, XC7VX690T-2FFG1761C,
XC7VX690T-3FFG1761E, XC7V585T-2FFG1761C

HTG-510
Altera
Stratix V™ PCI Express / Networking Development Platform

8-lanePCI Express Gen3 platform with two QSFP+ (2x40G), two SFP+ (2x10G), three QDR II components, two DDR3 SODIMM Sockets (up to 16GB) , one FMC HPC connectors (8 serial transceivers), two Samtec QSE/QTE connectors with 10 serial transceivers for board to board interface, CPLD, EPCS , and USB/UART port
More Info..
Supported FPGA Devices:
5SGXMA5K2F40C2N, 5SGXMA7K2F40C2N , 5SGXMA9K2H40C2N,  5SGXMABK2H40C2N

HTG-640
Xilinx Virtex 6 HXT 40G/100G  Interlaken Development Platform

100 Gig Development platform with two Interlaken interfaces (12x11Gbps ), DDR3, QDR II , CFP/SFP+ , four FMC connectors (132 single-ended I/Os and 32 GTX transceivers, GPIOs, and Samtec QSE connectors (8 GTX)
More Info..
Supported FPGA Devices:
XC6VHX380T-2FFG1923, XC6VHX565T-2FFG1923

HTG-503
Xilinx Virtex 5 Half-Length PCI Express Development Platform

4-Lane Gen 2 PCI Express platform with 8 data-rate-adjustable serial transceiver GTP/GTX  Ports,  DDR2 SODIMM (up to 2GB),  one 10/100/1000 Ethernet port, two Samtec QSE expansion ports (52 pairs LVDS),  and BPI Flash
More Info..
Supported FPGA Devices:
XC5VFX70T-2FF1136, XC5VFX100T-2/3FF1136
XC5VLX50T-1FF1136, XC5VSX95T-2FF1136

HTG-600
Xilinx Virtex 6 PCI Express Gen 2 Platform

8-Lane Gen 2 PCI Express platform with  two FMC  HPC  Connectors , one DDR3 SODIMM socket (up to 8GB), one Samtec QSE connector (32 LVDS pairs), USB 3.0/2.0 Host & Device connectors,  two 10/100/1000 Ethernet ports,  two SFP ports, SMA Connectors, IP Protection Circuit and BPI Flash
More Info..
Supported FPGA Devices:
XC6VLX240T-2/3FFG1759 , XC6VLX365T-2/3FFG1759,
XC6VLX550T-1/2FFG1759 , XC6VSX475T-2FFG1759

HTG-500
Altera Stratix V half-size PCI Express Development Platform

8-lane PCI Express Gen 3 half-size platform  with two QSFP+ (2x40G) , DDR3 components (5GB), QDR II (288Mb),  GPS, board-to-board connectors (LVDS and serial transceivers) , Serial EPCS flash, CPLD, programmable clocks, and mini USB/UART port
More Info..
Supported FPGA Devices:
5SGXMA5K2F40C2N, 5SGXMA7K2F40C2N , 5SGXMA9K2H40C2N,  5SGXMABK2H40C2N

HTG-530
Xilinx Virtex 5 PCI Express Development Platform


8-Lane Gen 2 PCI Express platform with  two SATA ports, one DDR2 SODIMM socket (up to 2GB), two data-rate-adjustable serial transceiver ports, two 10/100/1000 Ethernet ports, two SMA ports (serial), two Samtec QSE expansion ports ( 64 LVDS pairs)
More Info.
Supported FPGA Devices:
XC5VLX330T-2FF1738, XC5VFX200T-2FF1738
XC5VSX240T-2FF173
