Main Features:
PCI Express Features
· ►
Compliant to PCI Express Base Specification Revision 1.0a
· ►
Compliant to PCI Express to PCI Bridge Specification Revision 1.0
· ►
Support Single One-Lane PCI Express Connection
· ►
Support 32-bit CRC Covering All Transmitted Data Packets
· ►
Support 16-bit CRC On All Link Message Information
· ►
Support PCI Express Advanced Error Reporting Capability
· ►
Support Error Forwarding Including Data Poisoning and PCI Bus Parity
Errors.
· ►
Support 100MHz PCI Express Differential Reference Clock.
· ►
Secondary Side Initialization via Type 0 Configuration Cycles
· ►
Support Variable Payload Size (up to 512 bytes)
· ►
Support Variable Size of Read Request (up to 512 bytes)
PCI Interface Features
· ►
Compliant to PCI Local Bus Specification Revision 3.0
· ►
Support PCI 32-bit, 33/66 MHz, 3.3V, NOT 5V tolerant
· ►
Support Five External REQ/GNT Pairs For Internal Arbiter
· ►
Support PCI LOCK Operation
· ►
Support up to Two PCI Delayed Transaction (memory read, I/O read/write,
and configuration read/write)
· ►
Support Clock Run Operation
· ►
Support Five 33MHz/66MHz PCI Clock Outputs
Power Management
· ►
Support D0, D1, D2, D3hot and D3cold device power states defined in PCI
Power Management Specification Rev 1.1
· ►
Support PME event propagation on behalf of PCI devices
· ►
Side-band WAKE# signals
· ►
PCI Express Active Power Management states (ASPM) : L0s and L1
· ►
Support link power management: L0, L0s, L1, L2
· ►
In-band beacon generation
· ►
Integrated AUX Power Plane
SMBus Interface
· ►
Compliant to System Management Bus Specification, Revision 2.0
· ►
Support Slave-mode operation only
· ►
Support configuration of PCI Express PHY via SMBus
Price:
(Please include the quantity)
Part Number:
GL9701
